Proflex 5

NON-TOXIC IMPACT-RESISTANT VINYL RESINCO-EXTRUSION (PVC)
PROFLEX 5 is a range of technical expansion joint profiles for floors laid with glue/adhesive. They are made in non-toxic, impact-resistant, co-extruded PVC with perforated horizontal lateral flanges in rigid PVC while the elastic central part is made in flexible vinyl resin 5 mm in width. They are able to absorb moderate tensile and compressive stress, while being resistant to most chemical agents, to wear and to UV rays. They may be used indoors and outdoors. Thanks to the limited widths, PROFLEX 5 may be considered a “gap cover” because it blends in with the gaps between tiles. The joint profile must never be placed over a tiled floor and should preferably always be 0.5-1 mm lower. Recommended modules of application 16-30 m2

A series of advanced expansion joints for glue/adhesive-laid floors. Made from impact-resistant, non-toxic, co-extruded PVC. Able to absorb moderate tensile and compressive stress.


3D VIEW means that you can view product in 3D (in a pop up window) » click to install 3D View Plugin. Click the product images below left to view.
PFX5 045...1Pcs
NON - TOXIC CO-EXTRUDED VINYL RESIN

PROFLEX 5 is a range of technical expansion joint profiles for floors laid with glue/adhesive. They are made in non-toxic, impact-resistant, co-extruded PVC with perforated horizontal lateral flanges in rigid PVC while the elastic central part is made in flexible vinyl resin 5 mm in width. They are able to absorb moderate tensile and compressive stress, while being resistant to most chemical agents, to wear and to UV rays. They may be used indoors and outdoors. Thanks to the limited widths, PROFLEX 5 may be considered a “gap cover” because it blends in with the gaps between tiles. The joint profile must never be placed over a tiled floor and should preferably always be 0.5-1 mm lower. Lay the joints according with the standards in force.



Dimension: bar length 2,5 lm pack. 40 Pcs - 100 lm (PFX5 15 - pack. 20 Pcs - 50 lm)

Click to view product

Pack Size

Colour

Our Price
NZ$ 26.05
(NZ$ 22.65 ex GST)

Quantity
